Silicon is being re-founded from the transistor up
Designed Before the Thing It Runs

Almost every chip serving AI today was architected for a world that no longer exists — training-dominant, general-purpose, conceived before the transformer became the only architecture that mattered. The next decade rebuilds silicon around inference at civilizational scale.

Inference
Now the majority of AI compute spend
20–50%
Flops actually used on a GPU (MFU)
4,000 → ~3 ns
Chip-to-chip today vs light-speed floor
Token factory
The destination · fab-like scale
01
The three levers that actually move

Strip away the hype and the gains in purpose-built inference silicon come from exactly three places. Each tells you where the roadmap goes.

Lever 1 · heat
Thermal & voltage
V² ∝ power
You can’t just add flops — the chip throttles to avoid cooking itself. Dennard scaling: halve the voltage, quarter the power. Solve thermals first, then add flops. The future is low-voltage silicon.
Lever 2 · memory
Bandwidth & the interconnect
1000× gap
Decode is a memory game. The bottleneck isn’t on-chip bandwidth — it’s chip-to-chip latency. The direction: pool an entire cluster into one coherent memory across near-light-speed links.
Lever 3 · focus
Specialization
no ice
The whole stack is general-purpose “buffer.” Commit to one workload and break assumptions — no datacenter runs at 0°C, so drop the cold-corner timing. The 20%s compound into 10×.
02
Inference is two workloads, soon more

Prefill and decode have opposite hardware appetites. Running both on one undifferentiated chip satisfies neither. The answer is disaggregation — a pipeline of specialized chips, each doing the part it was born for.

Prefill · compute-bound
Load the gun
Read the prompt, get the model’s working memory into state. Wants raw flops.
hand off KV cache
Decode · memory-bound · splits further
Attention
High-bandwidth memory chip
Feed-forward
SRAM accelerator, older node
03
The destination: the token factory

Today we make tokens the way the Renaissance made screws — one at a time, by hand, on general-purpose machines. The endpoint is fab-like: cost per token falls as the facility grows.

Today
Handcrafted tokens · no economies of scale
$40B fab
The known unit economics of scale
$100B factory
One or a few models, a whole population
$1T token factory
Inevitable · the fab’s economics, applied to thought
Production is the product. Availability becomes the killer feature — a chip 10× better but in the thousands loses to one merely good and in the millions.
04
The re-founding is visible — and so is the bear case

Capital believes the workload is specializing. But the physics bet and the adoption bet are not the same bet.

The signal
  • Merchant inference ASICs arriving with working silicon, $1B+ in contracts, gigawatt-scale roadmaps
  • Groq’s inference tech absorbed into NVIDIA (~$20B)
  • Cerebras public at large valuations; custom-chip shipments projected to outgrow GPUs
The honest bear case
  • Architecture lock-in: a transformer ASIC is obsolete the day a post-transformer design wins. The GPU’s inefficiency is its insurance.
  • No independent benchmarks yet — the numbers are vendor-claimed.
  • NVIDIA’s moat is software. A proprietary toolchain asks customers to abandon what they know.
05
The layer I actually care about

If token production becomes a majority of output, and national capacity is measured in agents per gigawatt, the token supply chain becomes the most strategic chokepoint on Earth.

The sovereignty question under the spec sheet
Whoever controls the means of producing tokens controls the means of producing intelligence itself — and that chokepoint is narrow.
Leading-edge fabs
High-bandwidth memory
Gigawatts of power

This is the strongest argument I know for the local-first, open-weight posture: keep meaningful capability distributed — models you can run yourself, on hardware you own, close enough to the frontier to matter. Scale pulls one way; sovereignty and resilience pull the other. Both futures get built at once.

The question isn’t whether inference silicon specializes — it will.
It’s who owns the factories when it does, and whether the answer is “many.”

Impact of Purpose-Built Hardware on AI Scalability

This shift to workload-specific hardware could dramatically improve the efficiency and scalability of AI deployment, enabling models to serve hundreds of millions of users more sustainably. It challenges the long-standing reliance on general-purpose GPUs, potentially reshaping the entire AI hardware industry and reducing chokepoints in AI infrastructure.

By focusing on physics-based improvements and specialization, this approach could lead to more energy-efficient, cost-effective, and scalable AI systems, impacting everything from data center design to AI service economics.
